| Place of Origin: | China |
|---|---|
| Brand Name: | PLINK |
| Model Number: | Orin32-8F4E1 |
| Minimum Order Quantity: | 1set |
| Price: | To be negotiated |
| Delivery Time: | 15-30 work days |
| Payment Terms: | T/T, D/P, D/A, L/C |
| Supply Ability: | Batch purchase price negotiation |
| NAME: | Medical Industrial Embedded PC NVIDIA Jetson AGX Orin 32G 900-13701-0040-000 High Performance 200 TOPS | Keyword: | Medical Industrial Embedded PC NVIDIA Jetson AGX Orin 32G 900-13701-0040-000 High Performance 200 TOPS |
|---|---|---|---|
| AI Perf: | 200 TOPS | Temperature: | -20~+65°C |
| DLA Max Frequency: | 1.4 GHz | GPU Max Frequency: | 930 MHz |
| Power Supply: | AC 220 V | Memory: | 32GB 256-bit LPDDR5 204.8GB/s |
| USB Type-A: | 2 X USB 3.1 | Size: | 335mm*257mm*146mm |
| Weight: | 5500g | Storage: | 64GB EMMC 5.1 |
| High Light: | 2 x USB 3.1 Embedded Pc Industrial,200 TOPS Embedded Pc Industrial,900-13701-0040-000 Single Board Computer |
||
|
Power requirements
|
220V
|
|
Weight
|
5050g
|
|
Working temperature
|
-20~+65°C
|
|
Product size
|
146mm×335mm×257 mm
|
|
AI Performance
|
200 TOPS
|
|
Power
|
15W - 40W
|
|
Memory
|
32GB 256-bit LPDDR5
204.8GB/s |
|
GPU
|
1,792-core NVIDIA Ampere architecture GPU with 56 Tensor Cores
|
|
CPU
|
8-core Arm® Cortex®-A78AE v8.2 64-bit CPU
2MB L2 + 4MB L3 |
|
Other I/O
|
4x UART, 3x SPI, 4x I2S, 8x I2C, 2x CAN, PWM, DMIC & DSPK, GPIOs
|
|
|
RTX 6000
|
RTX A6000
|
|
GPU Memory
|
24GB GDDR6
|
48GB GDDR6
|
|
NVIDIA CUDA Cores
|
4608
|
10752
|
|
NVIDIA Tensor Cores
|
576
|
336
|
|
NVIDIA RT cores
|
72
|
84
|
|
NVIDIA NVLink bandwidth
|
100GB/s (bidirectional)
|
112.5GB/s (bidirectional)
|
|
Error-correcting code (ECC)
|
Yes
|
Yes
|
|
Single-Precision Performance
|
16.3 TFLOPS
|
38.7 TFLOPS
|
|
Tensor Performance
|
130.5 TFLOPS
|
309.7 TFLOPS
|
|
System Interface
|
PCI Express 3.0 x 16
|
PCI Express 4.0 x 16
|
