| Place of Origin: | China |
|---|---|
| Brand Name: | PLINK |
| Model Number: | NX16G-SYS-2006 |
| Minimum Order Quantity: | 1set |
| Price: | To be negotiated |
| Delivery Time: | 15-30 work days |
| Payment Terms: | T/T, D/P, D/A, L/C |
| Supply Ability: | Batch purchase price negotiation |
| NAME: | Programmable UAV Module Embedded Computer Mini PC Jetson Xavier NX 16G | Keyword: | Programmable UAV Module Embedded Computer Mini PC Jetson Xavier NX 16G |
|---|---|---|---|
| AI Performance: | 21 TOPS | GPU: | 384-core NVIDIA Volta™ GPU With 48 Tensor Cores |
| CPU: | 6-core NVIDIA Carmel Arm®v8.2 64-bit CPU 6MB L2 + 4MB L3 | Type-A: | USB 3.1*1 USB 2.0*2 |
| Micro USB: | Micro USB*1 | Memory: | 16GB 128-bit LPDDR4x 59.7GB/s |
| PCIe: | 1 X1 (PCIe Gen3) + 1 X4 (PCIe Gen4), Total 144 GT/s* | HDMI: | HDMI 2.0 Interface (MAX 6Gbps，24bpp，4096x2160@60Hz) |
| Networking: | 10/100/1000 BASE-T Ethernet | Display: | 2 Multi-mode DP 1.4/eDP 1.4/HDMI 2.0 No DSI Support |
| Size: | 160mm × 130mm × 65mm | Weight: | 1078g |
| Power: | DC +9V~+24V | Working Temperature: | -25~+65°C |
| High Light: | UAV Module fanless embedded computer,Programmable UAV fanless embedded computer,UAV Module embedded mini pc |
||
Programmable UAV Module Embedded Computer Mini PC Jetson Xavier NX 16G
NX16G-SYS-2006 is an industrial embedded computer compact programmable with NVIDIA Jetson Xavier NX series core modules. also it is an embedded mini pc for industrial deployment applications, the main interfaces are designed for electrostatic safety protection, and a high-reliability power supply application scheme is adopted. The input power supply has overvoltage and reverse polarity protection functions, and has a wealth of external interfaces. warm model.
Size:160mm×130mm×65mm
Power:DC +9V~+24V
Temperature Range: -25~+65°C
|
USB 3.1 Type-A |
1x |
|
USB 2.0 Type-A |
2x |
|
Micro USB |
1x |
|
HDMI 2.0 |
1x |
|
Work indicator light |
1x |
| Micro TF Card | 1x |
| SIM Card | 1x |
|
Pre-installed NVIDIA Jetson Xavier NX core modules |
|
|
Optional with 32GB~1TB SSD extended storage |
|
| The power is automatically turned on | |
|
Optional 1 / 3 / 5 Gigabit Ethernet |
|
The NVIDIA Jetson Xavier NX enables AI at the edge with powerful computing performance, while keeping the small form factor of the Jetson Nano. This makes it possible to deploy containerized Azure solutions with AI acceleration at scale for applications like processing multiple camera feeds, more sophisticated robotics applications, and edge AI gateway scenarios.
NVIDIA Jetson Xavier NX Module
NVIDIA Jetson Xavier NX is production-ready and supports all popular AI frameworks. This opens new possibilities for embedded edge-computing devices that demand increased performance to support AI workloads but are constrained by size, weight, power budget, or cost.
NVIDIA Jetson Xavier NX Specifications
| CPU | 6-core NVIDIA Carmel ARM®v8.2 64-bit CPU 6MB L2 + 4MB L3 |
| Memory | 16 GB 128-bit LPDDR4x 59.7GB/s |
| GPU | 384-core NVIDIA Volta™ GPU with 48 Tensor Cores |
| AI Performance | 21 TOPS |
| CSI Camera | Up to 6 cameras (24 via virtual channels) 14 lanes (3x4 or 6x2) MIPI CSI-2 D-PHY 1.2 (up to 30 Gbps) |
| Video Encode | 2x 4K60 | 4x 4K30 | 10x 1080p60 | 22x 1080p30 (H.265) 2x 4K60 | 4x 4K30 | 10x 1080p60 | 20x 1080p30 (H.264) |
| Video Decode | 2x 8K30 | 6x 4K60 | 12x 4K30 | 22x 1080p60 | 44x 1080p30 (H.265) 2x 4K60 | 6x 4K30 | 10x 1080p60 | 22x 1080p30 (H.264) |
| Vision Accelerator | 7-Way VLIW Vision Processor |
