| Place of Origin: | China |
|---|---|
| Brand Name: | PLINK |
| Model Number: | Y-C1-E1 |
| Minimum Order Quantity: | 1PCS |
| Price: | USD70\pcs |
| Delivery Time: | 15-30 work days |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | In stock |
| NAME: | Industrial Expansion Embedded PC Board Nvidia Jetson Tx2 Module 15W | Key Word: | Industrial Expansion Embedded PC Board Nvidia Jetson Tx2 Module 15W |
|---|---|---|---|
| Micro HDMI: | X1 MAX6Gbps，24bpp，4096x2160@60Hz | Full Length MiniPCie Slot: | X1 Supports PCIE X1, USB2.0 Signals |
| Half Length MiniPCie Slot: | X1 Supports PCIE X1, USB2.0 Signals MSata SSD | Board Size: | 87mm×60mm×15mm |
| Weight: | 24g | Temperature: | -40~+85℃ |
| High Light: | 15W Embedded PC Board,Tx2 Embedded PC Board,Industrial nvidia jetson tx2 module |
||
Industrial Expansion Embedded PC Board Nvidia Jetson Tx2 Module 15W
Embedded Computer Module: NVIDIA Jetson TX2 Module
Pascal GPU + ARMv8 + LPDDR4 + eMMC
The Y-C1 is an industrial carrier board for NVIDIA Jetson TX2/TX2-4GB modules, it is an embedded development board for face recognition and V2X, The input power supply is 7.5W-15.
|
Product Name |
NVIDIA Jetson TX2 Carrier Board Y-C1-E1 |
| AI Performance | 1.33 TFLOPS |
| GPU | NVIDIA Pascal™ architecture with 256 NVIDIA CUDA cores 1.3 TFLOPS (FP16) |
| CPU | Dual-core NVIDIA Denver 2 64-bit CPU and quad-core Arm® Cortex®-A57 MPCore processor complex |
| Memory | 8 GB 128-bit LPDDR4 59.7 GB/s |
| Power | 7.5W | 15W |
| PCIe | 1 x4 + 1 x1 OR 2 x1 + 1 x2 PCIe Gen 2, total 50GT/s |
| CSI Camera | Up to 6 cameras (12 via virtual channels) 12 lanes MIPI CSI-2 (3x4 or 6x2), D-PHY 1.2 (up to 30 Gbps) |
| Video Encode | 1x 4K60 | 3x 4K30 | 4x 1080p60 | 8x 1080p30 (H.265) 1x 4K60 | 3x 4K30 | 7x 1080p60 | 14x 1080p30 (H.264) |
| Video Decode | 2x 4K60 | 4x 4K30 | 7x 1080p60 | 14x 1080p30 (H.265 & H.264) |
| Display | 2 multi-mode DP 1.2/eDP 1.4/HDMI 2.0 2 x4 DSI (1.5Gbps/lane) |
| Networking | Wi-Fi onboard 10/100/1000 BASE-T Ethernet |
| Temperature Range | -40℃ to 85℃ |
| Size | 87mm × 60mm ×15mm |
| Weight | 24g |
|
Interface |
Quality |
|
Micro HDMI |
1 |
|
MiniPCIe |
2 |
|
FPC |
1 |
|
2x15 Pin |
1 |
|
Nano SIM Card |
1 |
|
1x4 Pin USB2.0 |
1 |
Jetson TX1/TX2 core modules can work in normal mode and recovery mode. In Recovery mode, file system update, kernel update, Boot loader update, BCT update and other operations can be performed.
The steps to enter Recovery mode are as follows:
Turn off the system power supply.
Use a Micro-USB cable to connect the Y-C1's Micro-USB port to the Jetson development host USB port.
Press and hold the RECOVERY button (S2) to supply power to the system for more than 3 seconds, then release the RECOVERY button
The system enters Recovery mode, at which point subsequent operations can be performed.
