| Place of Origin: | USA |
|---|---|
| Brand Name: | NVIDIA |
| Model Number: | AGX Orin Industrial module |
| Minimum Order Quantity: | 1pcs |
| Price: | To be discussed |
| Delivery Time: | To be discussed |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | To be discussed |
| NAME: | Driverless Autopilot Jetson AGX Orin Industrial Module Nvidia Ampere GPU 64G 900-13701-0080-000 | Keyword: | Driverless Autopilot Jetson AGX Orin Industrial Module Nvidia Ampere GPU 64G 900-13701-0080-000 |
|---|---|---|---|
| AI Performance: | 248 TOPS | Module Number: | AGX ORIN Industrial (900-13701-0080-000) |
| Power: | 15W-75W | Memory: | 64GB 256-bit LPDDR5 (+ ECC) 204.8GB/s |
| Storage: | 64GB EMMC 5.1 | GPU Max Frequency: | 1.2 GHz |
| High Light: | 64G AGX Orin Dev Kit,900-13701-0080-000 AGX Orin Dev Kit |
||
Driverless Autopilot Jetson AGX Orin Industrial Module Nvidia Ampere GPU 64G 900-13701-0080-000
NVIDIA Jetson AGX Orin Industrial Module 900-13701-0080-000
The NVIDIA® Jetson AGX Orin™ Industrial module 900-13701-0080-000 is up to 248 TOPs of AI Performance for edge computing, and the power configurable between 15W-75W. Jetson AGX Orin series of industrial modules, performance is 8 times that of Jetson AGX Xavier Industrial, more used in autonomous machines, such as manufacturing, construction, agriculture,energy, government and other industries. 2048-core NVIDIA Ampere architecture GPU with 64 Tensor Cores and 64GB 256-bit LPDDR5 (+ ECC) 204.8GB/s memory for the NVIDIA Jetson AGX Orin Industrial module 900-13701-0080-000
NVIDIA Jetson AGX Orin industrial Module 900-13701-0080-000 Technical Specifications
| AI Perf | 248 TOPs |
| GPU | 2048-core NVIDIA Ampere architecture GPU with 64 Tensor Cores |
| GPU Max Frequency | 1.2 GHz |
| CPU | 12-core Arm® Cortex®-A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3 |
| CPU Max Frequency | 2.0 GHz |
| Memory | 64GB 256-bit LPDDR5 (+ ECC) 204.8GB/s |
| Storage | 64GB eMMC 5.1 |
| Video Encode | 1x 4K60 (H.265) 3x 4K30 (H.265) 7x 1080p60 (H.265) 15x 1080p30 (H.265) |
| Video Decode | 1x 8K30 (H.265) 3x 4K60 (H.265) 7x 4K30 (H.265) 11x 1080p60 (H.265) 23x 1080p30 (H.265) |
| CSI Camera | Up to 6 cameras (16 via virtual channels) 16 lanes MIPI CSI-2 D-PHY 2.1 (up to 40Gbps) | C-PHY 2.0 (up to 164Gbps) |
| Power | 15W-75W |
| Mechanical | 100mm x 87mm 699-pin Molex Mirror Mezz Connector Integrated Thermal Transfer Plate |
