| Place of Origin: | China |
|---|---|
| Brand Name: | PLINK |
| Model Number: | ORIN64-8F5E2 |
| Minimum Order Quantity: | 1SET |
| Price: | To be negotiated |
| Delivery Time: | 15-30 work days |
| Payment Terms: | T/T, D/P, D/A, L/C |
| Supply Ability: | Batch purchase price negotiation |
| NAME: | Desktop Industrial Embedded Box PC NVIDIA Jetson AGX Orin 64GB HPC | Keyword: | Desktop Industrial Embedded Box PC NVIDIA Jetson AGX Orin 64GB HPC |
|---|---|---|---|
| Brand: | PLINK | AI Performance: | 275 TOPS |
| Memory: | 64GB 256-bit LPDDR5 204.8GB/s | Storage: | 64GB EMMC 5.1 |
| GPIO(3.3V): | 4* | SPI(3.3V): | 1* |
| Type B (OTG): | 1* | USB 3.1: | 2* |
| Networking: | 2* RJ45 | I2C(3.3V): | 2* |
| RS 232: | 2* | Debug(UART): | 1* |
| CAN: | 2* | Size: | 238 Mm × 222 Mm × 67 Mm |
| Weight: | 2950g | ||
| High Light: | 64GB industrial embedded box pc,Jetson industrial embedded box pc,HPC embedded desktop |
||
Desktop Industrial Embedded Box PC NVIDIA Jetson AGX Orin 64GB HPC
Embedded IPC NVIDIA Jetson AGX Orin 64GB
ORIN64-8F5E2 Embedded Computer
ORIN64-8F5E2 is an industrial embedded box pc, it is compare with NVIDIA Jetson AGX Orin module and which is for V2X, autopilot and all the autonomous machine.
2048-core NVIDIA Ampere architecture GPU with 64 tensor cores
64GB 256-bit LPDDR5
64GB eMMC 5.1
Voltage input 5V, 7V-20V
Power Breakthroughs in Healthcare and Life Sciences
Advance medicine and research with AI
Healthcare demands new computing paradigms to meet the need for personalized medicine, next-generation clinics, enhanced quality of care, and breakthroughs in biomedical research to treat disease. With NVIDIA, healthcare institutions can harness the power of artificial intelligence (AI) and high-performance computing (HPC) to define the future of medicine.
With accelerated computing, researchers can virtually model millions of molecules and screen hundreds of potential drugs at a time, reducing costs and speeding time to solution.
Using HPC to accelerate genome analysis in population and cancer genomic studies can help identify rare diseases and bring tailored therapeutics to market faster, advancing the journey to precision medicine.
AI-powered tools can be an extra set of “eyes”, helping clinicians to quickly detect and measure anomalies, uplevel surgeons' skills, enhance image quality, and optimize workflows.
From smart sensors to advanced image processing, AI at the edge can deliver immediate insights, optimizing patient care and realizing the promise of smart hospitals.
Product Features
| AI Performance |
275 TOPS |
| CPU | 12-core Arm® Cortex®-A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3 |
| GPU | 2048-core NVIDIA Ampere GPU with 64 Tensor Cores |
| Memory | 64GB 256-bit LPDDR5 204.8 GB/s |
| Storage | 64GB eMMC 5.1 |
| Debug(UART) | 1* |
| USB 3.1 | 2* |
| GPIO(3.3V) | 4* |
| RS 232 | 2* |
| I2C(3.3V) | 2* |
| SPI(3.3V) | 1* |
| CAN | 1* |
| Type B (OTG) | 1* |
| RJ45 | 2* |
| Temperature | -25~+65°C |
| Power | DC + 12V |
| Size | 238 mm × 222 mm × 67 mm |
| Weight | 2950g |
