| Place of Origin: | China |
|---|---|
| Brand Name: | Leadtek |
| Model Number: | WinFast GS2040T |
| Minimum Order Quantity: | 1 |
| Delivery Time: | 30-45 work days |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | To be discussed |
| NAME: | Leadtek WinFast GS2040T PC Workstation Server For AI Deep Learning 3D Rendering | Keyword: | Leadtek WinFast GS2040T PC Workstation Server For AI Deep Learning 3D Rendering |
|---|---|---|---|
| CPU: | Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors Support CPU TDP 270W Up To 40 Cores | Memory Capacity: | 16 DIMM Slots Up To 4TB 3DS ECC DDR4-3200MH RDIMM/LRDIMM Supports Intel® Optane™ DCPMM |
| Memory Type: | 3200/2933/2666MHz ECC DDR4 RDIMM/LRDIMM | Chipset: | Intel® C621A Chipset |
| SATA: | SATA3 (6Gbps) With RAID 0, 1, 5, 10 | Network Controllers: | Dual Port 10GbE From Intel X710 |
| Height: | 3.46"(88mm) | Width: | 30.18"(766.8mm) |
| Weight: | Net Weight: 39.5 Lbs (17.9 Kg) Gross Weight: 54 Lbs (24.5 Kg) | ||
| High Light: | Leadtek WinFast GS2040T Nvidia GPU Server,Dual Port 10gbe Nvidia GPU Server |
||
Leadtek WinFast GS2040T PC Workstation Server For AI Deep Learning 3D Rendering
WinFast GS2040T features a powerful GPU architecture that supports up to 6 double-width passive GPUs (NVIDIA® A100/A40/A30/A10) or 4 double-width active GPUs(NVIDIA® RTX A6000/A5000), enable scaling of performance in order to meet the demands of AI, high-performance computing, and 3D rendering applications.
Optimized for AI/Deep Learning GPU peering
Optimized for NVIDIA GRID
Supports up to 6 double-wide GPU cards
Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors
16 DIMMs; up to 4TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM,
Supports Intel® Optane™ DCPMM
6 PCI-E 4.0 x16 slots (FHFL),
2 PCI-E 4.0 x8 slot
Support up to 6 pcs of Double-width GPUs
Dual 10GBase-T LAN ports
10x 2.5" Hot-swap SATA/SAS drive bays, up to 6x 2.5" NVMe
5x 8cm heavy duty fans with optimal fan speed control
2600W (1+1) Redundant Power Supplies Titanium Level (96%)
Processor
|
CPU |
Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors Support CPU TDP 270W Up to 40 Cores |
System Memory
| Memory Capacity | 16 DIMM slots Up to 4TB 3DS ECC DDR4-3200MH RDIMM/LRDIMM Supports Intel® Optane™ DCPMM |
| Memory Type | 3200/2933/2666MHz ECC DDR4 RDIMM/LRDIMM |
On-Board Devices
| Chipset | Intel® C621A chipset |
| SATA | SATA3 (6Gbps) with RAID 0, 1, 5, 10 |
| Network Controllers | Dual Port 10GbE from Intel X710 |
Input/Output
| SATA | 8 SATA3 (6Gbps) ports |
| LAN | 2 RJ45 10GBase-T LAN ports |
| 1 RJ45 Dedicated IPMI LAN port | |
| USB | 2 USB 3.0 ports (rear) 2 USB 2.0 ports (front) |
| Video | 1 VGA Connector |
Dimensions and Weight
| Height | 3.46"(88mm) |
| Width | 17.35"(440.7mm) |
| Depth | 30.18"(766.8mm) |
| Weight | Net Weight: 39.5 lbs (17.9 kg) |
| Gross Weight: 54 lbs (24.5 kg) |
| Form Factor | 2U Rackmountable with Rail kit |
Expansion Slots
| PCI-Express | 6 PCI-E 4.0 x16 slots |
| 2 PCI-E 4.0 x8 slots |
System Cooling
| Fans | 5x 8cm Heavy duty fans with optimal fan speed control |
Power Supply
| Power | 2600W 1U Redundant Power Supplies with PMBus |
| AC Input | 2600W: 200-240Vac / 15A Max |
| DC Input | 2600W: 200-240Vdc For CQC Only/ 15A Max / 50-60Hz |
| +12V | Max: 216A / Min: 0A (11.4Vdc-12.6Vdc) (12V output) |
Operating Environment
| RoHS | RoHS Compliant |
| Environmental Spec. |
Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
